Fiber Core Diameter
LSZH - Low Smoke Zero Halogen (Flame Retardent)
900 μm µm
Number of Active Subunits
Fibers Per Subunit
0.078 in (2.0 mm)
Subunit Strength Members
Central Strength Member
LSZH - Low Smoke Zero Halogen (Flame Retardant)
0.358 in (9.1 mm)
Number of Ripcords
Min. Bend Radius During Installation
15x Cable OD
Min. Bend Radius During Operation
10x Cable OD
Max. Tensile Strength During Installation
1330 N (300 lbf)
Max. Tensile Strength During Operation
400 N (90 lbf)
Bulk Cable Weight
20 lbs/kft (30 kg/km)
Installation Temperature Range
-10°C to +60°C
Operating Temperature Range
-40°C to +70°C
Storage Temperature Range
CA Prop 65
Flammability / Reaction to Fire
Update and Revision
Revision Number: 0.76 Revision Date: 04-08-2022
