9623

Electronic, 5 C #14 Str TC, PVC Ins, PVC Jkt

...
Electronic, 5 Conductor 14AWG (19x27) Tinned Copper, PVC Insulation, PVC Outer Jacket
English
Request Quote
Share
Request Sample Get Product Alerts

Specifications
Report An Error
Product Overview

Suitable Applications

up to 600V analog signals ; up to 600V control ; line level audio; voice communications; panel wiring

Construction Details
Conductor
Element No. of Elements Size Stranding Material
Conductor(s) 5 14 AWG 19x27 TC - Tinned Copper
Insulation
Element Material Nom. Thickness Nom. Insulation Diameter Color Code
Conductor(s) PVC - Polyvinyl Chloride 0.045 in (1.1 mm) 0.166 in (4.22 mm) Black, White, Red, Green, Orange
Outer Jacket
Separator Material Nom. Thickness Nom. Diameter
PP - Polypropylene Tape PVC - Polyvinyl Chloride 0.060 in (1.5 mm) 0.573 in (14.6 mm)

Overall Cable Diameter (Nominal)

0.573 in (14.6 mm)

Electrical Characteristics
Electricals
Element Nom. Conductor DCR Nom. Capacitance Cond-to-Cond Max. Current
Conductor(s) 2.8 Ohm/1000ft 18 pF/ft (59 pF/m) 7.5 Amps per Conductor at 25ºC
Voltage
Voltage Rating
600 V
Mechanical Characteristics
Temperature
Operating
-20°C To +80°C

Max. Pull Tension

237 lbs (108 kg)

Bulk Cable Weight

183 lbs/1000ft

Standards and Compliance

Environmental Suitability

Indoor (Not Riser or Plenum), Indoor

Flammability / Reaction to Fire

UL 1581 (VW-1), VW-1

European Directive Compliance

EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)

APAC Compliance

China RoHS II (GB/T 26572-2011)

History

Update and Revision

Revision Number: 0.485 Revision Date: 01-20-2023

Show All Specifications
Hide Specifications
Part Numbers
Item # Color UPC Footnote
9623 0601000 Chrome 612825256786 C
9623 060500 Chrome 612825256793 C
