F Connectors - DB58UHF

Double Bubble RG58 "F" connector, fits standard RG58 50 Ohm coaxial cable. Compression design that molds the metal completely around the cable. 25 per Pack

Availability:

Global
Status:

Active

Quote

DB58UHF

Specifications
Part Numbers
Resources

Specifications

Product Overview

Suitable Applications	UHF Antenna, 50 Ohm

Physical Characteristics (Overall)

Packaging	25 Pack
Number of Pieces	1

Connectors

Materials

Material
Nickel plated Brass
Gold Plated

Electrical Characteristics

Impedance

Nominal Characteristic Impedance
50 Ohm

Mechanical Characteristics

Connector System Compatibility	Coax
Connector Interface Type	F
Gender	Male - plug
Connector Series Name	Double Bubble
Locking	No
Tool Compatibility	CPLCRBC-BR (compression)
Termination Type	Compression

Cable Center Conductor Diameter Limits	.0317 - .0339 inch
Cable Dielectric Diameter Limits	.0111 - .121 inch
Cable Outer Jacket Diameter Limits	.185 - .201 inch

Standards

RG Type	58

Applicable Environmental and Other Programs

EU CE Mark	Yes

Suitability

Suitability - Indoor	Yes

Related Part Numbers

Footnote	Q - STANDARD PACKAGES CANNOT BE BROKEN.

Patent	This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents.

History

Update and Revision	Revision Number: 0.110 Revision Date: 02-20-2026

Information

Update and Revision	Revision Number: 0.110 Revision Date: 02-20-2026

Report An Error

Part Numbers

Item #	Color	UPC
DB58UHF	No Color	845671000221
