Applicable for high flexible (up to 5 million flex cycles) installation connecting precision control sensors, multi axis control machines, temperature controllers, control panels, machine cutting tools, auxiliary equipment, motor speed control, production machinery and many more in noisy industrial environment.
Installation Temp Range
-40°C to +80°C
Operating Temp Range
0°C to +70°C
Bulk Cable Weight
Min. Bend Radius During Installation
Min Bend Radius During Operation
7.5 x OD
Min No. of Drag Chain Cycles
≥ 5,000,000 Cycles ( 1 m Travel Distance, 20cycles/min, 1.5m/s), ≥ 1,000,000 Cycles ( 3 m Travel Distance, Travel Speed 3m/s, Acceleration 10m/s), ≥ 200,000 Cycles ( 5MT Traverse Distance, 20cycles/min, 1.5m/s)
Drag Chain Parameters
1m Travel Distance, 20cycles/min, 1.5m/s
EN 50525-2-11, EN 50525-2-51, VDE 0281-13, VDE-PB-0022
Third Party Performance Verification
VDE Certification No. 40051701, VDE Registration No. F743
EU Directive 2011/65/EU (RoHS 2)
MII Order #39 (China RoHS)
Suitability - Indoor
Suitability - Oil Resistance
Suitability - Outdoor
Suitability - Sunlight Resistance
DIN VDE 0482‐332‐1‐2
Update and Revision
Revision Number: 0.36 Revision Date: 08-27-2021
