direct burial, serial communication (RS-485 standard) comprising of PLCs, VFDs, HMIs, motors, RTU, SCADA, etc. within noisy environments over long distance, outdoor such as solar, lighting, etc.
Overall Cable Diameter (Nominal)
0.387 in (9.83 mm)
Nom. Outer Shield DCR
3.663 Ohm/1000ft (12.02 Ohm/km)
Max. Pull Tension
80 lbs (36 kg)
Bulk Cable Weight
Indoor, Outdoor, Sunlight Resistance, Oil Resistance
Flammability / Reaction to Fire
UL 1685 UL Loading, FT1, IEC 60332-1-2
NEC / UL Compliance
Article 725, Article 800, CM, PLTC
CEC / C(UL) Compliance
European Directive Compliance
EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
China RoHS II (GB/T 26572-2011)
Oil Resistance: Passes Oil Res I & II Per UL1277, Table 10.17
Update and Revision
Revision Number: 0.213 Revision Date: 06-30-2022
