Product Number: ZV 2 4-3-225

T-Splitter, Sensor/Actuator, double M12 3 pole female, with Black PUR cable

T-Splitter, Sensor/Actuator, M12 to M12, IP67, PUR orange body, 3-pin M12 Female to 3-pin M12 female, 63 V, 4 A, with PUR, black jacket, 4x0.34mm² cable

  • Availability:
    Global
  • Status:
    Active
ZV 2 4-3-225
  • ZV 2 4-3-225
1 of 1
  • Where to buy

Specifications

Report An Error

Product Family

Sensor / Actuator Connectors

Connector Type

T-Splitter

Shielding

Unshielded

Rated Voltage

63 V

Rated Impulse Voltage

1.5 kV

Operating Voltage

50 V AC / 60 V DC

Rated Current*

4 A

Product Sub Family

M12 Standard

Type of Contact / Gender

2 x Female

Connector Design

T Body

Attachment Type

Coupling Nut

Number of Pins

4

Coding

A

Contact Resistance

≤ 5 mOhm

Insulation Resistance

˃ 10^9 Ohm

Mating Cycles

≤ 100

Ambient Temperature (Operation)*

- 25 °C - + 80 °C

Protection Degree / IP Rating**

IP65, IP67

Design Standard

IEC 61076-2-101

Pollution Degree

3 acc. to DIN EN 60664-1 (VDE 0110-1)

Overvoltage Category

III acc. to DIN EN 60664-1 (VDE 0110-1)

Contact Base Material

CuSn

Contact Plating

Cu/Au

Contact Bearer Material

TPU

Contact Bearer Color

Black

Flammability Class (Contact Bearer)

UL 94 HB

Molded Body Material

TPU

Molded Body Color

Orange

Flammability Class (Molded Body)

UL 94 HB

Attachment Material

CuZn

Attachment Plating

1xNickel-plated, 1xNylon Black coated

O-Ring Material

FKM, green

Fastening Torque (Attachment)

M 12x1: (50-60) Ncm, hand-tight

Cable Number

225

Conductor Size

0.34 mm²

Number of Wires

4

Minimal Bending Radius (Fixed Inst)

5 x D

Minimal Bending Radius (Flexible Inst)

10 x D

Cycles (Bending)

5 M

Cycles (Torsion)

˃ 3 M @ ± 360 °/1 m

Conductor material

Cu

Cable Jacket Material

PUR

Cable Jacket Color

black matt similarly RAL 9005

Cable Diameter D

ø 4.70 ± 0.15 mm

Wire Insulation Material

PP

Insulated Wire Diameter

ø 1.30 ± 0.15 mm

Ambient Temperature (Fixed Installation)

- 50 °C - + 90 °C (UL: + 80 °C)

Ambient Temperature (Flex Installation)

- 25 °C - + 90 °C (UL: + 80 °C)

Ambient Temperature (Drag Chain Inst)

- 25 °C - + 60 °C

UL Cable Type

AWM: 20549

Flammability Class (Cable Jacket)

DIN EN 60332-2-2, VDE 0482-332-2-2, IEC 60332-2-2, CSA FT-2

Cable Characteristics

Good microbes and hydrolysis resistance; Mainly plasticizer diffusion free; Exclusion of PVC and silicone; Coldness flexibility; Free of lacquer wetting disturbing substances

RoHS Compliant

Yes

Halogenfree

Yes

Oil Resistance

Yes

Note Derating

Notice derating

Note Derating

Notice derating

Part Numbers

Item # Item Description Cable Length
23368 ZV 2 4-3-225/15 M 15 m
43780 ZV 2 4-3-225/10 M 10 m
43782 ZV 2 4-3-225/2 M 2 m
43783 ZV 2 4-3-225/5 M 5 m
