Central Loose Tube Fiber Cable

Universal (Indoor/Outdoor) optical fiber Central Loose Tube (jelly filled tube) cable with glass yarns as strength member, Low Smoke Zero Halogen inner jacket, Steel Wire Armouring (Full Rodent Protected) armor and Low Smoke Zero Halogen outer jacket. Product feature: This cable has improved rodent protection by Steel Wire Armouring (Full Rodent Protected). Existing out of 1 Tube with a diameter of 3.3mm with 12 fibers MM OM1. CPR Euroclass Dca.

Availability:

Global
Status:

Active

Quote

Specifications
Part Numbers
Resources

Specifications

Expand All

Product Overview

Suitable Applications	For outdoor and indoor use in structured (data) wiring systems such as industrial backbone, campus backbone, building backbone (riser) and/or horizontal cabling. For outdoor and indoor use in networks for industrial, telecom, cable TV and/or broadcast. Easy to install in ducts, tunnels and trenches and/or tubes. Suitable for Direct Burial.

Fiber Specifications

Fiber Type	OM1
Fiber Count	12
Fiber Color Coding	TIA coding (Gxxxxxx.T): Blue, Orange, Green, Brown, Gray, White, Red, Black, Yellow, Violet, Pink, Aqua

Cable Construction

Number of Active Subunits	1
Fibers Per Subunit	12
Subunit Waterblocking	Gel Filled
Subunit Diameter	3.3 mm
Subunit Color	TIA coding (Gxxxxxx.T): Natural
Cable Core Water Blocking	Waterblocking Glass Yarns

Inner Jacket Specifications

Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)
Nominal Diameter@InnerJacket1 (cnv)	5.8 mm (0.23 in)

Armor Specifications

Armor Type and Material	SWA - Steel Wire Armor

Outer Jacket Specifications

Jacket Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)
Nom. Diameter	10.2 mm (0.402 in)

Optical Characteristics

Wavelength	850 nm	1300 nm
Max. Attenuation	3.4 dB/km	0.9 dB/km

Mechanical Characteristics

Mechanical Tests

Description	Tested Standard	Requirement/Value	According to Family Specification
Cable Min. Bend Radius Installation (Short Term)	IEC 60794-1-21-E6	192 mm	IEC 60794-3-10
Cable Min. Bend Radius Operation (Long Term)	IEC 60794-1-21-E11	192 mm	IEC 60794-3-10
Cable Max. Tensile Strength Installation (Short Term)	IEC 60794-1-21-E1	1500 N (340 lbf)	IEC 60794-3-10
Cable Max. Tensile Strength Operation (Long Term)	IEC 60794-1-21-E1	500 N (110 lbf)	IEC 60794-3-10
Cable Max. Crush Resistance Installation (Short Term)	IEC 60794-1-21-E3	22 kN/m	IEC 60794-3-10
Cable Max. Crush Resistance Operation (Long Term)	IEC 60794-1-21-E3	11 kN/m	IEC 60794-3-10

Bulk Cable Weight	154 kg/km (103 lbs/1000ft)

Temperature Range

Installation Temperature Range	-5 °C to +50 °C
Operating Temperature Range	-30 °C to +55 °C
Storage Temperature Range	-30 °C to +55 °C

Standards and Compliance

Environmental Suitability	Indoor/Outdoor - Euroclass Dca
Flammability / Reaction to Fire	IEC 60332-1-2
CPR Compliance	CPR Euroclass: Dca-s1,d2,a1; CPR UKCA Class: Dca-s1,d2,a1
ISO/IEC Compliance	IEC 60794ISO/IEC 11801-1
European Halogen Free Standards	IEC 60754-1 - Halogen Amount = Zero, IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity = 10 µS/mm, IEC 60754-2 - Halogen Acid Gas Amount - Min. pH = 4.3, IEC 61034-2 - Smoke Density Min. Transmittance = 60%
UK Regulation Compliance	UKCA Mark
