LC1AS24B

KeyConnect Loaded CAT6A Straight Patch Panel, 24 Port, 1U

KeyConnect Loaded CAT6A Straight Patch Panel, 24 Port, 1U, Black fitted with Bracket & bar and pre-loaded with Modular Jack

Request Quote

Share

Get Product Alerts

Specifications

Report An Error

Color
Black

Port Count	24 Port
Packaging	Individually packaged in a cardboard box.

Description	Material
Panel	Steel
Front Connection – Jack	Copper Alloy with 50µ Gold over Nickel
Rear Connection – Jack	Copper Alloy with Nickel Plating
Jack Body	Plastic – UL940V-4

Max Capacity	24 connectors

Dielectric Strength	1000 V RMS @ 60 Hz for 1 minute
Insulation Resistance	500 MOhm Minimum
Contact Resistance (Switch Contact)	20 mOhm

Max. Recommended Current [A]
1.5 A

Installation Temperature Range	-10⁰C to +60⁰C
Storage Temperature Range	-40⁰C to +70⁰C
Operating Temperature Range	-10⁰C to +60⁰C

Footprint/Type	KeyConnect
Plug /Jack Compatibility	RJ45, RJ11

Termination	Connection	Durabilities
Front	Mated Type – Flush and Straight Connection	750 Cycles
Rear	Termination Type IDC Connection	20 Terminations

Data Category	Category 6A

Environmental Space	Indoor
EU Directive 2011/65/EU (RoHS 2)	Yes
MII Order #39 (China RoHS)	EUP 50

Included Parts	X Bar for Jacks, 4 Screws (10X32), 4 Screws (12X24), 1 Installation Guide, 1 Ground Wire 24 AWG Kit (For Flat Panels Only)

Update and Revision	Revision Number: 0.16 Revision Date: 04-08-2022
