Product Number: 50957

Security & Sound, 2 Conductor 1.5 mm², BC, Unshielded

Security & Commercial Audio Cable, 2 core 1.5 mm² stranded bare copper conductors with PVC insulation, PVC jacket with ripcord

  • Availability:
    Asia Pacific
  • Status:
    Active
50957
5 of 5

Specifications

Expand All

Suitable Applications

Monitor/Detection, Control Circuits, Initiating Circuits, Notification Circuits

Conductor

Size Stranding Material
1.5 mm² Stranded BC - Bare Copper

Insulation

Material Nom. Insulation Diameter Color Code
PVC - Polyvinyl Chloride 2.9 mm (0.11 in) Black, Red

Outer Shield

Material
No Shield

Outer Jacket

Material Nom. Diameter Ripcord
PVC - Polyvinyl Chloride 7.40 mm Yes

Electricals

Max. Conductor DCR
13.3 Ohm/km

Temperature

Operating
0°C To +70°C

Bulk Cable Weight

66 kg/km (44 lbs/1000ft)

Environmental Suitability

Indoor

European Directive Compliance

EU Directive 2011/65/EU (RoHS 2)

Update and Revision

Revision Number: 0.40 Revision Date: 09-07-2025

Update and Revision

Revision Number: 0.40 Revision Date: 09-07-2025


Report An Error

Part Numbers

Item # Color Length
(IT_50957 010305M_SAPEU_NTICOS)
50957 010305M Black 305 m
50957 010500M Black 500 m
50957 008305M Grey 305 m
50957 008500M Grey 500 m
50957 003305M Orange 305 m
50957 003500M Orange 500 m
50957 002305M Red 305 m
50957 002500M Red 500 m
