Product Number: 1671J

Conformable Coax, 50 Ohm RG-405, 24 AWG Solid SCCS, Copper-Tin Composite Shield, PVC Jacket

Conformable Coax, 50 Ohm, RG-405, 24 AWG Solid Silvered Copper Covered Steel Conductor, PTFE Insulation, Copper Tape + 100% Tin-Filled Composite Braid Shield, PVC Jacket

  • Availability:
    Global
  • Global inventory:
    Available
1671J
  • 1671J
1 of 1

Specifications

Report An Error

Suitable Applications

Microwave and other high frequency applications, Interconnect RF equipment, Radar equipment, Military communications

RG Type

405

Conductor

No. of Elements Size Stranding Nom. Diameter Material
1 24 AWG Solid 0.0201 in SCCS - Silvered Copper Covered Steel

Insulation

Material Nom. Insulation Diameter Color Code
PTFE - Polytetrafluoroethylene 0.062 in (1.6 mm) White

Outer Shield

Layer Outer Shield Type Material Material Trade Name Coverage
1 Tape Bare Copper (BC) Beldfoil® 100%
2 Braid Tinned Copper (TC + Tin Filled) 100%

Outer Jacket

Material Nom. Diameter
PVC - Polyvinyl Chloride 0.127 in (3.23 mm)

Overall Cable Diameter (Nominal)

0.127 in (3.23 mm)

VSWR

Frequency Max. VSWR
500 MHz 1.1:1
20000 MHz 1.3:1

Attenuation

Frequency Nom. Attenuation
500 MHz 15 dB/100ft
1000 MHz 22.2 dB/100ft
2000 MHz 32.8 dB/100ft
3000 MHz 41.2 dB/100ft
5000 MHz 54.9 dB/100ft
7000 MHz 66.4 dB/100ft
10000 MHz 81.2 dB/100ft
15000 MHz 102.dB/100ft
18000 MHz 113 dB/100ft
20000 MHz 120 dB/100ft

Power Rating

Frequency Max. Power Rating
500 MHz 180 W
1,000 MHz 119 W
2,000 MHz 79 W
3,000 MHz 62 W
5,000 MHz 46 W
7,000 MHz 37 W
10,000 MHz 30 W
15,000 MHz 24 W
18,000 MHz 21 W
20,000 MHz 20 W

Electricals

Nom. Conductor DCR Nom. Outer Shield DCR Nom. Capacitance Cond-to-Shield Nom. Characteristic Impedance Nom. Velocity of Prop.
64.2 Ohm/1000ft (211 Ohm/km) 10.2 Ohm/1000ft (33.5 Ohm/km) 29.5 pF/ft (96.8 pF/m) 50 Ohm 70%

Voltage

UL Voltage Rating Voltage Rating
30 V RMS 1500 V RMS

Temperature

UL Temperature Operating
105°C -40°C To +105°C

Bend Radius

Stationary Min. Installation Min. Flexing Min.
1 in (25 mm) .125 in (3.18 mm) .375 in (9.53 mm)

Max. Pull Tension

26 lbs (12 kg)

Bulk Cable Weight

16 lbs/1000 ft

Environmental Suitability

Indoor/Outdoor, Indoor, Outdoor

Flammability / Reaction to Fire

Horizontal Wire

AWM Compliance

AWM 10245 (30 V 105°C)

European Directive Compliance

EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)

APAC Compliance

China RoHS II (GB/T 26572-2011)

Notes

Teflon® is a registered trademark of E. I. duPont de Nemours and Co. used under license by Belden, Inc.

Update and Revision

Revision Number: 0.392 Revision Date: 02-03-2025

Update and Revision

Revision Number: 0.392 Revision Date: 02-03-2025

Part Numbers

Item # Color Putup Type Length UPC Footnote
1671J 010100 Black Reel 100 ft 612825120315
1671J 010500 Black Reel 500 ft 612825120339 V
1671J 0101000 Black Reel 1,000 ft 612825120322 V
