19402

Portable Cordage, 3 C #18 Str BC, PVC Ins, PVC Jkt, UL Type SVT

...
Portable Cordage, 3 Conductor 18AWG (42x34) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SVT
English
Request Quote
Share
Request Sample Get Product Alerts

Specifications
Report An Error
Product Overview

Suitable Applications

Portable cordage for supplying power to appliances and tools

Construction Details
Conductor
Element No. of Elements Size Stranding Material Notes
Conductor(s) 3 18 AWG 42x34 BC - Bare Copper 0.824mm2
Insulation
Element Material Nom. Thickness Nom. Insulation Diameter Color Code
Conductor(s) PVC - Polyvinyl Chloride 0.018 in (0.46 mm) 0.084 in (2.1 mm) Light Blue, Brown, Green/Yellow
Outer Jacket
Separator Material Nom. Thickness Nom. Diameter
Paper Tape PVC - Polyvinyl Chloride 0.034 in (0.86 mm) 0.253 in (6.43 mm)

Overall Cable Diameter (Nominal)

0.253 in (6.43 mm)

Electrical Characteristics
Electricals
Element Nom. Conductor DCR Max. Current
Conductor(s) 6.66 Ohm/1000ft 7 Amps per conductor @ 30°C
Voltage
UL Voltage Rating
(Type SVT)
Mechanical Characteristics
Temperature
UL Temperature Operating
60°C -20°C to +60°C
Bend Radius
Stationary Min. Installation Min.
2.5 in (64 mm) 2.5 in (64 mm)

Max. Pull Tension

61.5 lbs (27.9 kg)

Bulk Cable Weight

39 lbs/1000ft

Standards and Compliance

NEC / UL Compliance

SVT

AWM Compliance

SVT

European Directive Compliance

EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)

APAC Compliance

China RoHS II (GB/T 26572-2011)

History

Update and Revision

Revision Number: 0.523 Revision Date: 05-11-2023

Show All Specifications
Hide Specifications
Part Numbers
Item # Color Putup Type Length UPC Footnote
19402 010250 Black Reel 250 ft 612825127048 F
