8890

Lead Wire, #24 Str TC, EPDM Ins

...
Low Temp Rubber Lead Wire, 24AWG (45x40) Tinned Copper, EPDM Insulation, 1000V 90C
English
Request Quote
Share
Request Sample Get Product Alerts

Specifications
Report An Error
Product Overview

Suitable Applications

used as test probe lead for electrical and electronic measuring for test equipment

Construction Details
Conductor
Element No. of Elements Size Stranding Material
Conductor(s) 1 24 45x40 TC - Tinned Copper
Insulation
Material Nom. Thickness
EPDM - Ethylene Propylene Diene Monomer 0.019 in (0.48 mm)

Overall Cable Diameter (Nominal)

0.066 in (1.7 mm)

Electrical Characteristics
Electricals
Nom. Conductor DCR
24.2 Ohm/1000ft
Voltage
Voltage Rating Breakdown Voltage
1000 V 10,000 V
Mechanical Characteristics
Bend Radius
Stationary Min. Installation Min.
0.27 in (6.9 mm) 0.27 in (6.9 mm)

Max. Pull Tension

5.9 lbs (2.7 kg)

Bulk Cable Weight

3.3 lbs/1000ft

Standards and Compliance

Sustainability

CA Prop 65

European Directive Compliance

EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)

APAC Compliance

China RoHS II (GB/T 26572-2011)

Product Notes

Notes

10000 V Breakdown

History

Update and Revision

Revision Number: 0.458 Revision Date: 01-20-2023

Show All Specifications
Hide Specifications
Part Numbers
Item # Color Putup Type Length UPC
8890 010100 Black Reel 100 ft 612825217534
8890 010500 Black Reel 500 ft 612825217541
8890 002100 Red Reel 100 ft 612825217510
8890 002500 Red Reel 500 ft 612825217527
