BE43007

Lead Wire, 0.4mm² Solid CN, PVC Ins, 70°C

...
PVC 0.4mm CuNi
English
Request Quote
Share
Get Product Alerts
Specifications
Report An Error
Product Overview

Suitable Applications

Single core non-sheathed cable with solid conductor for internal wiring for conductor temperatures up to 70C

Physical Characteristics (Overall)
Conductor
Stranding Material Nominal Diameter
Solid BCA - Bare Copper Alloy 0.4 mm

Table Notes

Alloy is Copper-Nickel

Conductor Count

1

Insulation
Type Material Nominal Diameter Diameter +/- Tolerance Min. Wall Thickness Nominal Wall Thickness
Insulation PVC - Polyvinyl Chloride 0.82 mm 0.05 mm 0.175 mm 0.41 mm
Construction and Dimensions

Min Elongation at Breakof Conductors

5 %
Electrical Characteristics
Voltage
Voltage Test (In Line)
1 kV AC
Standards

UL AWM Style Compliance

N/A

Military Compliance

N/A

Applicable Environmental and Other Programs

Environmental Space

Indoor
Flammability, LS0H, Toxicity Testing

C(UL) Flammability

VW-1

UL voltage rating

N/A

History

Update and Revision

Revision Number: 0.142 Revision Date: 04-08-2022

Show All Specifications
Hide Specifications
Part Numbers
Item # Color Put-Up Type Length EAN
BE43007.0010K Black Reel 10,000 m 8719605026293
BE43007.0210K Brown Reel 10,000 m 8719605026316
BE43007.0310K Green Reel 10,000 m 8719605026323
BE43007.0110K White Reel 10,000 m 8719605026309
