Fiber Core Diameter
PVC - Polyvinyl Chloride
900 μm µm
Fiber Color Coding
Number of Active Subunits
Fibers Per Subunit
0.078 in (2.0 mm)
Subunit Strength Members
Central Strength Member
0.23 in (5.9 mm)
Number of Ripcords
Min. Bend Radius During Installation
15x Cable OD
Min. Bend Radius During Operation
10x Cable OD
Max. Tensile Strength During Installation
1330 N (300 lbf)
Max. Tensile Strength During Operation
400 N (90 lbf)
Bulk Cable Weight
14 lbs/kft (21 kg/km)
Installation Temperature Range
-0°C to +60°C
Operating Temperature Range
-0°C to +70°C
Storage Temperature Range
-40°C to +70°C
CA Prop 65, Product Lens™
Flammability / Reaction to Fire
Update and Revision
Revision Number: 0.57 Revision Date: 04-08-2022
