Industrial Control, Raceways Cable trays and ducts, Digital Control, Instruments (4-20ma, 0-10v, ...),low voltage digital control (24v, …), encoders, control circuits, distributed control system (DCS),programmable logic controller (PLC), Solenoids, Valves, Actuators, Positioners
Overall Cable Diameter (Nominal)
0.980 in (24.9 mm)
Max. Pull Tension
1031 lbs (467.7 kg)
Bulk Cable Weight
Indoor/Outdoor, Indoor, Outdoor, Sunlight Resistance
Flammability / Reaction to Fire
UL1685 (FT4 Loading), FT4, 1202
NEC / UL Compliance
Article 725, Article 727, Article 800, CMG, PLTC-ER, ITC-ER
CEC / C(UL) Compliance
European Directive Compliance
EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
China RoHS II (GB/T 26572-2011)
Update and Revision
Revision Number: 0.384 Revision Date: 07-07-2022
