Instrumentation, Sensors, Valves, Positioners, 4-20mA, 0-10V
Overall Cable Diameter (Nominal)
0.466 in (11.8 mm)
Max. Pull Tension
220 lbs (100 kg)
Bulk Cable Weight
Indoor/Outdoor, Indoor, Outdoor, Sunlight Resistance, Burial
Flammability / Reaction to Fire
UL 1685 UL Loading, FT4, FT4, T-29-520, IEEE 1202
NEC / UL Compliance
Article 725, Article 727, Article 800, CMG, ITC-ER, PLTC-ER
CEC / C(UL) Compliance
European Directive Compliance
EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
China RoHS II (GB/T 26572-2011)
Update and Revision
Revision Number: 0.545 Revision Date: 11-09-2022
