Distributed Antenna Systems (DAS), Passive Optical Network (PON), Wireless Access Points (WAP), Security (Cameras)
Fiber Core Diameter
PVC - Polyvinyl Chloride
Fiber Color Coding
Subunit Strength Members
Waterblocking aramid yarns
Fibers Per Subunit
Nom. Jacket Diameter
0.180 in. (4.6 mm)
Number of Strands
TC - Tinned Copper
Number of Conductors
Nom. Insulation Diameter
0.052 in. (1.3 mm)
0.347 in (8.9 mm)
Number of Ripcords
Min. Bend Radius During Installation
15x Cable OD
Min. Bend Radius During Operation
10x Cable OD
Max. Tensile Strength During Installation
1335 N (300 lbf)
Max. Tensile Strength During Operation
400 N (90 lbf)
Bulk Cable Weight
46 lbs/kft (69 kg/km)
Installation Temperature Range
0°C to +60°C
Operating Temperature Range
-40°C to +70°C
Storage Temperature Range
Indoor/Outdoor, Sunlight Resistance, Burial
CA Prop 65
NEC / UL Compliance
Update and Revision
Revision Number: 0.47 Revision Date: 04-08-2022
