Product Sub Family
Type of Contact / Gender
Number of Pins
Rated Impulse Voltage
230 V AC/DC
10 A (0.75 mm²)
≤ 10 mOhm
Type of Connection
Conductor Cross Section
max. 0.75 mm²
Ø6 mm to Ø12 mm,
Gasket Ø9 mm for cables with Ø6 - 9 mm,
Gasket Ø12 mm for cables with Ø9 - 12 mm
Ambient Temperature (Operation)*
-40°C to +90°C, notice derating
Temperature Range (Gasket)
-40°C to +90°C
Protection Degree / IP Rating**
DIN EN 61984 (VDE 0627)
3 acc. to DIN EN 60664-1 (VDE 0110-1)
Clearance / Creepage Distance
DIN EN 60664-1 (2008/01); VDE 0110-1
Contact Base Material
Contact Bearer Material
PA 66 GF
Contact Bearer Color
Flammability Class (Contact Bearer)
UL 94 V-0
Flammability Class (Attachment)
Fastening Torque (Cable Gland)
TR22: min. 250 Ncm
Mating Connectors / Fitting to
934-126-100 CA 6 LS (field attachable, straight),
934-130-100 CA 6 W LS (field attachable, angled),
932-326-100 CA 6 GS (receptacle, straight)
Accessories to Order Separately
CA00 SD 3: 831-532-400, cap
E95522, Series CA 3
* Notice derating
Protection Degree / IP Rating Note
** only if mounted and locked in combination with Hirschmann / Lumberg Automation connector.
Do not connect or disconnect under load.
