Product Number: WireMesh Tray Downward Elbow-S

CWT-D90-xx - Series

WireMesh Tray Downward-elbow 90°-section

  • Availability:
    EMEA
  • Status:
    Active
WireMesh Tray Downward Elbow-S
  • WireMesh Tray Downward Elbow-S
1 of 1

Specifications

Expand All

Environmental Space

Indoor

Mechanical Characteristics Note

For assembling to Wire Mesh Tray, Screw & Bolt Set CWT-S-xx can be used

Finish

Galvanized

Material

Steel

Color

Metal

Update and Revision

Revision Number: 0.104 Revision Date: 01-17-2025

Update and Revision

Revision Number: 0.104 Revision Date: 01-17-2025


Report An Error

Part Numbers

Part # [A] Tray Width [B] [C]
CWT-D90-05 50 mm 210 mm 50 mm
CWT-D90-10 100 mm 210 mm 50 mm
CWT-D90-20 200 mm 210 mm 50 mm
CWT-D90-30 300 mm 210 mm 50 mm
