Product Number: WireMesh Tray Reducer

CWT-R-xx/xx-13 - Series

WireMesh Tray Reducer

  • Availability:
    EMEA
  • Status:
    Active
WireMesh Tray Reducer
  • WireMesh Tray Reducer
1 of 1

Specifications

Expand All

Environmental Space

Indoor

Mechanical Characteristics Note

For assembling to Wire Mesh Tray, Screw & Bolt Set CWT-S-xx can be used

Finish

Galvanized

Material

Steel

Color

Metal

Update and Revision

Revision Number: 0.36 Revision Date: 08-17-2023

Update and Revision

Revision Number: 0.36 Revision Date: 08-17-2023


Report An Error

Part Numbers

Part # Description [A] 1st Tray width [B] 2nd Tray width [C]
CWT-R-10/05-13 WireMesh Tray Reducer 100mm to 50 mm 100 mm 50 mm 50 mm
CWT-R-20/10-13 WireMesh Tray Reducer 200 mm to 100 mm 200 mm 100 mm 50 mm
CWT-R-30/20-13 WireMesh Tray Reducer 300 mm to 200 mm 300 mm 200 mm 50 mm
