Product Number: BASES E-SERIES

EDAB2xxx - Series

Bases for E-Serie Cabinets with knockouts for cable entry. The base is constructed out of two side profiles which correspond to the depth of the cabinet, and two cover panels (front and back) with a corresponding width. .

  • Availability:
    EMEA
  • Status:
    Active
BASES E-SERIES
  • BASES E-SERIES
1 of 1

Specifications

Expand All

Environmental Space

Indoor

Overall Height

120 mm

Mechanical Construction Note

TIP: The base is prepared for installation of stabilisers EDAB101x, which are highly recommended to use on cabinets with sliding servers.

Load Capacity

1900 kg

Finish

Powder Coated

Material

Steel

EU Directive 2011/65/EU (RoHS 2)

Yes

MII Order #39 (China RoHS)

EUP 50

Included Parts

2x side base profile with a cable entry (with knockout-type blanking panels), 2x cover with cable entry (with knockout-type blanking panels), 1 cover with filter, 1 anti dust brush, fasteners

Packaging

Individually packed.

Update and Revision

Revision Number: 0.183 Revision Date: 07-11-2025

Included Parts

2x side base profile with a cable entry (with knockout-type blanking panels), 2x cover with cable entry (with knockout-type blanking panels), 1 cover with filter, 1 anti dust brush, fasteners

Packaging

Individually packed.

Update and Revision

Revision Number: 0.183 Revision Date: 07-11-2025


Report An Error

Part Numbers

Item # Width Depth Color Application
EDAB2611 600 1,000 Gray E-Series Cabinets
EDAB2612 600 1,000 Black E-Series Cabinets
EDAB2621 600 1,200 Gray E-Series Cabinets
EDAB2622 600 1,200 Black E-Series Cabinets
EDAB2681 600 800 Gray E-Series Cabinets
EDAB2682 600 800 Black E-Series Cabinets
EDAB2811 800 1,000 Gray E-Series Cabinets
EDAB2812 800 1,000 Black E-Series Cabinets
EDAB2821 800 1,200 Gray E-Series Cabinets
EDAB2822 800 1,200 Black E-Series Cabinets
EDAB2881 800 800 Gray E-Series Cabinets
EDAB2882 800 800 Black E-Series Cabinets
