5624UG

Nurse Call & Paging, #24-6c, BC, Unshielded, CM

...
Nurse Call & Paging Cable, Rated-CM, 6-24 AWG solid bare copper conductors with polyolefin insulation, PVC jacket
Get Product Alerts
Specifications
Product Overview

Suitable Applications

Nurse Call, Commerical Sound, Annunciators, Voice Systems, Paging

Physical Characteristics (Overall)
Conductor
AWG Stranding Material Nominal Diameter No. of Conductors
24 Solid BC - Bare Copper 0.020 in 6

Conductor Count

6

Insulation
Material Nominal Diameter
PP - Polypropylene 0.033 in
Color Chart
Number Color
1 Blue
2 Black
3 Orange
4 Red
5 Green
6 White
Outer Jacket
Material Nominal Diameter
PVC - Polyvinyl Chloride 0.081 x 0.246 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
25.9 Ohm/1000ft
Capacitance
Nom. Capacitance Conductor to Conductor
17 pF/ft
Current
Max. Recommended Current [A]
1.4 Amps per Conductor at 25ºC (10°C Temperature Rise)
Voltage
UL Voltage Rating
300 V RMS
Temperature Range

Operating Temp Range

-25°C To +75°C

Mechanical Characteristics

Bulk Cable Weight

17 lbs/1000ft

Max. Pull Tension

24 lbs

Standards

NEC/(UL) Compliance

CM

CEC/C(UL) Compliance

CM

Applicable Environmental and Other Programs

Environmental Space

Indoor Rated (Not Riser or Plenum)

EU Directive 2000/53/EC (ELV)

Yes

EU Directive 2003/11/EC (BFR)

Yes

EU Directive 2011/65/EU (RoHS 2)

Yes

EU Directive 2012/19/EU (WEEE)

Yes

EU Directive 2015/863/EU (RoHS 2 amendment)

Yes

EU Directive Compliance

EU Directive 2003/11/EC (BFR)

MII Order #39 (China RoHS)

Yes

Suitability

Suitability - Aerial

Yes - Black only, when supported by messenger wire

Suitability - Burial

No

Suitability - Hazardous Locations

No

Suitability - Indoor

Yes

Suitability - Outdoor

Yes - Black only

Flammability, LS0H, Toxicity Testing

UL Flammability

UL1685 UL Loading

UL voltage rating

300 V RMS

Plenum/Non-Plenum

Plenum (Y/N)

No

Plenum Number

6624UG

History

Update and Revision

Revision Number: 0.337 Revision Date: 08-27-2021

Part Numbers
Item # Color Put-Up Type Length UPC
5624UG F6H1000 Gray, Dark Pearl Reel 1,000 ft 612825164760
