Distributed Antenna Systems (DAS), Passive Optical Network (PON), Wireless Access Points (WAP), Security (Cameras)
Fiber Core Diameter
PVC - Polyvinyl Chloride
Fiber Color Coding
Subunit Strength Members
Fibers Per Subunit
Nom. Jacket Diameter
0.180 in. (4.6 mm)
Number of Strands
TC - Tinned Copper
Number of Conductors
Nom. Insulation Diameter
0.087 in. (2.2 mm)
LSZH - Low Smoke Zero Halogen (Flame Retardant)
0.422 in (10.8 mm)
Number of Ripcords
Min. Bend Radius During Installation
15x Cable OD
Min. Bend Radius During Operation
10x Cable OD
Max. Tensile Strength During Installation
1335 N (300 lbf)
Max. Tensile Strength During Operation
400 N (90 lbf)
Bulk Cable Weight
80 lbs/kft (120 kg/km)
Installation Temp Range
-10°C to +60°C
Operating Temp Range
-20°C to +70°C
Storage Temp Range
-40°C to +70°C
CA Prop 65
NEC / UL Compliance
Update and Revision
Revision Number: 0.19 Revision Date: 04-08-2022
